Input and DC-free line output applications
Line input and line output transformers for galvanic isolation, balanced-to-unbalanced conversion and for impedance conversion. Should be used with DC-free signal sources, or with a DC blocking capacitor between source and transformer.
For Breakout PCB's, check here
Input and DC-free line output applications
|
Model
|
Turns
Ratio
|
Size
LxWxH mm
|
Applications
|
Comments
|
Price
USD
|
|
1+1:4+4
|
43x28x21
|
Line in/output
|
Amorphous core line in/output transformer
|
134.00
|
|
|
1+1:2+2
|
43x28x21
|
Line in/output
|
Amorphous core line in/output transformer
|
134.00
|
|
|
1+1:1+1
|
42x28x22
|
High level general purpose
|
For high level, low impedance applications such as (DC decoupled) line output.
The transformer is not suitable for line input from high impedance signal sources.
|
128.00
|
|
|
1+1:1+1
|
42x28x22
|
High level line input
|
For high level, high impedance applications such as (DC free) line input
|
134.00
|
|
|
5.8+5.8:1+1
|
47x28x23
|
Line output
|
Mu metal lamination core
|
69.00
|
|
|
1+1:1+1
|
43x29x23
|
Line input
|
With Cardas high purity copper wire and Lundahl amorphous core
|
234.00
|
|
|
1+1:1+1
|
43x29x23
|
Line Input
|
Amorphous core with silver wire, specs same as the LL1948
|
914.00
|
|
|
2+2:1+1
|
47x28x24
|
Line in/output
|
With Cardas high purity copper wire. Most often used with solid state amplifiers
|
184.00
|
|
|
1+1+1+1:1+1+1+1
|
66x31x21
|
Line Input / General Purpose Transformers
|
The LL7901 has an extreme level capability ( + 34 dBU @ 50 Hz) while the LL7902 combines high level capability (+28 dBU @ 50 Hz) with low copper resistance
|
142.00
|
|
|
1+1+1+1:2+2+2+2
|
66x23x21
|
Mic or line input
|
200:213kΩ (used 1:8) This is the ultimate microphone input transformer, designed for high quality tube equipment.
|
143.00
|
|
|
LL7903Ag
|
1+1+1+1:2+2+2+2
|
66x23x21
|
Mic or line input
|
200:213kΩ (used 1:8) This is the ultimate microphone input transformer, designed for high quality tube equipment, silver wire.
|
767.00
|
|
1+1+1+1:5.6+5.6
|
66x32x21
|
+16dBU
|
Improved version of the LL7905. Also available in silver wire, please contact us for pricing.
|
143.00
|
To place an order, please click here
Breakout pcb's for Lundahl audio transformers
